Price 325000.0 INR/ Unit

MOQ : 1 Unit

Mobile Bitumen Sprayer Specification

  • Mount Type
  • Tractor
  • Tank Material
  • Mild Steel
  • Tank Dimensions (Mm X Mm X Mm)
  • 200*150*138
  • Fuel Type
  • Diesel
  • Driven Type
  • Tractor
  • Coverage Area
  • 1200 Square Millimeter (mm2)
  • Working Width
  • 1200mm
  • Material
  • Mild Steel
  • Capacity
  • 2500 Ltr
  • Computerized
  • No
  • Automatic Grade
  • Semi-Automatic
  • Cooling System
  • Human Machine Interface
  • Color
  • Black and Yellow
  • Weight
  • 2000 Kilograms (kg)
  • Warranty
  • 12Months


Mobile Bitumen Sprayer Trade Information

  • Minimum Order Quantity
  • 1 Unit
  • Payment Terms
  • Cash in Advance (CID)
  • Supply Ability
  • 5 Units Per Month
  • Delivery Time
  • 5 Days
  • Sample Available
  • Yes
  • Packaging Details
  • Standard Packaging
  • Main Export Market(s)
  • Asia
  • Main Domestic Market
  • All India
  • Certifications
  • ISO


About Mobile Bitumen Sprayer

  • Model                                      -                   SKE - 2500
  • Capacity                               -            2500 Ltrs
  • Length - L                              -          2000 mm
  • Width - W                             -    1500 mm
  • Height - H                            -        1380 mm
  • Bitumen input hole      -        750 mm
  • Insulation                           -          40 mm Glass Wool
  • Shape                                    -           U-Trapazoidal
  • Spraying Arrangement  -  Hand Spary Nozzle with 2 nos.                                                                                   Handled gun pip. S.S. Corrugated                                                                           Spray pipe for hot bitumen. OR R-2                                                                       Rubber Hose pipe for Emulsion
  • Bitumen Pump        -           1.5 x 1.5 / 2 x 2 Size Pressure Pump                                                                           specially design for hot bitumen and                                                                 emulsion bitumen
  • Reduction Gear         -          3 NU Worm type driven by pully - V Belt                                                             system by engine
  • Air Blower                 -                  Twin Lobe Blower/2 HP - 2800 RPM. Air                                                                 Blower Driven by Pulley - v Belt                                                                                  by engine for burner combusting
  • Burner                  -                  Bozzer Burner/L.A.P Type, Fuel Tank : 50                                                            ltr
  • Wood Bhatti                 -        6 mm thich for wooden fire furnace                                                                    middle at tank with chimney and ash                                                                removal
  • Axle Types (Four Tyre)       - Rear - 1 No. 7 x 50 16 Font - 1 No. 7 x 50                                                                   x16 (Tyre - 4 Nos.)
  • Axle Types (Two Tyre)      - Rear - 1 No. Rear - 9 x 16 (Tyre - 2 Nos.)
  • Temperature gauge          - 0 - 300 C
  • Drum Lifting                  -         Drum Loading by 1 ton. Cap Chain                                                                          Pulley block - movable to tank                                                                                bitumen input hole
  • Engine                      -              Kirlosker make or ISI make 6 HP / 6.5                                                                    HP / 7.5 HP / 8 HP / 10 HP AT 1500 rpm
  • Cleaning                         -      Unique pressure cleaning system after                                                            used of spraying by L.D.O / Kerosine /                                                                  Diesel.
